Wilcox Industries BOSS Xe Optical System

EACH UNIT INCLUDES WILCOX PRESSURE PAD AND MOUNT

The Wilcox BOSS Xe™, a class 3B high power laser aiming device, is an easy to use, small form factor sighting system designed specifically for the Military and LE markets. The BOSS Xe features a fully integrated, environmentally stable optical bench that houses a smart red dot/reflex sight, red or green visible laser, NIR laser, fixed NIR VCSEL illuminator, and iron sight all co-aligned with one another. An Above-the-Rail IR Room illuminator improves target visibility and provides proper IR lighting for close quarters battle. The unique windage and elevation adjustments allow operators to quickly and easily set one zero for the entire optical bench. User defined functions on the remote pressure pad allow for a “heads up, eye out” posture adding further customization options for the operator.

The Wilcox BOSSTM Xe is the next generation in the BOSS line of products. As a class 3R low power laser or 3B high power laser aiming device, the BOSS Xe is designed specifically for the military and law enforcement markets. The BOSS Xe features a fully integrated, environmentally stable optical bench that houses a smart reflex sight, red visible laser, NIR laser, fixed NIR VCSEL illuminator, and iron sight all co-aligned to one another. The fixed NIR illuminator, combined with the newly added NIR room illuminator, features best in class overall effective tactical solution in any low light tactical situation.

Decisively designed with the operator in mind, the BOSS Xe differentiates itself from any other reflex sight on the market. The user can fire either supersonic or subsonic ammunition from the same weapon by simply flipping a trajectory selection switch that changes the point of aim and point of impact of each round fired without having to re-zero the weapon.

When the BOSS Xe is securely mounted to any Picatinny style 1913 rail, it provides rock solid boresight retention.

The use of one windage and elevation adjustor combined with the trajectory switch delivers repeatable accuracy that can’t be found with any other fire control system on the market. Finite adjustments can be made to the trajectory switch to accommodate the drop differential between ammunition types. Wilcox has set the standards for optical performance in beam clarity and uniformity with extraordinary reduction in illuminator speckle, aiding in increasing the operator’s effectiveness and situational awareness.

The multi-function attributes are focused on maximizing engagement times during rapid target acquisition. An on-board maintenance counter monitors the total amounts of rounds fired from the weapon similar to an odometer in a vehicle. This real time-shared data with the depot’s armorer through the Armorer’s APP from BlueforceCOMMAND will enhance the maintenance of the weapon.

This smart reflex sight is one of a kind. Depending on weapon orientation, if off cant, the indicator will blink.

Features

One optical bench houses a red VIS laser, NIR laser, NIR room/fixed Illuminators, smart reflex sight, and iron sight

NIR VCSEL illuminator and wide angle NIR Room illuminator project precise, speckle-free beams for extreme clarity and optimal combat identification

Optical bench is aligned to weapon using one windage and one elevation adjustment

Powered by one (1) CR123 battery

Mounts to any 1913 Picatinny rail secured by 2 shock nuts

Multi-function buttons provide flexibility in programing custom options.

Selectable or auto adjustable laser/illuminator/reflex sight brightness settings

Remote port accepts Wilcox line of ERGOCTO™ Xe™ Activation Keypads and ERGOCTO Xe Control Grips (optional)

Bluetooth interface provides key information on mobile devices

Simultaneously maintains supersonic and subsonic zero with trajectory switch

Smart reflex sight features built-in back up iron sight

Smart reflex sight features a cant indicator if the weapon is off angle from the horizon
